Title: Fabrication of a 2D thermally tunable reflective grating for measuring a CO2 laser beam profile

Creator:

Riahi, Mohammadreza ; Latifi, Hamid

Contributor:

Gaj, Miron. Redakcja ; Urbańczyk, Wacław. Redakcja

Description:

Optica Applicata, Vol. 41, 2011, Nr 3, s. 735-742

Abstrakt:

In this article, application of a 2D thermally tunable reflective grating for measuring the beam profile of a CO2 laser is proposed. A 2D grating is first fabricated on a glass substrate by conventional lithography technique. The grooves of the grating are filled with nitrobenzene, the refractive index of which highly depends on temperature. A double side polished silicon wafer is then placed on the grating. If a CO2 laser is incoming from silicon side, a portion of it is transmitted and absorbed in the grating structure. Depending on the beam profile of the CO2 laser, a temperature profile is produced on the grating causing the same profile for efficiency of the grating for a visible light. The changes in the efficiency, cause changes in intensity of dif-fraction orders. By measuring the intensity of the first order of diffraction, the beam profile of the CO2 laser is imaged on a visible CCD camera.

Publisher:

Oficyna Wydawnicza Politechniki Wrocławskiej

Place of publication:

Wrocław

Date:

2011

Resource Type:

artykuł

Resource Identifier:

oai:dbc.wroc.pl:58186

Source:

<sygn. PWr A3481II> ; click here to follow the link ; click here to follow the link

Language:

eng

Relation:

Optica Applicata ; Optica Applicata, Vol. 41, 2011 ; Optica Applicata, Vol. 41, 2011, Nr 3 ; Politechnika Wrocławska. Wydział Podstawowych Problemów Techniki

Rights:

Wszystkie prawa zastrzeżone (Copyright)

Access Rights:

Dla wszystkich w zakresie dozwolonego użytku

Location:

Politechnika Wrocławska

Group publication title:

Optica Applicata
