Simulation and design of a wideband T-shaped photonic crystal splitter

Title: Simulation and design of a wideband T-shaped photonic crystal splitter

Creator:

Foghani, Shaghayegh ; Kaatuzian, Hassan ; Danaie, Mohammad

Contributor:

Gaj, Miron. Redakcja ; Urbańczyk, Wacław. Redakcja

Description:

Optica Applicata, Vol. 40, 2010, nr 4, s. 863-872

Abstrakt:

In this paper, a high efficiency 2-D T-shaped photonic crystal beam splitter is proposed. It consists of a square lattice of GaAs rods (n = 3.4) embedded in air. The photonic crystal structure proposed can be used for 1550 nm wavelength, which is an important wavelength for optical fiber data transmission. Finite difference time domain (FDTD) simulation results demonstrate that a conventional T-junction can only provide 78% transmission coefficient (39% for each branch) for the incident light, while the proposed T-shaped splitter transmits over 90% of the incident light beam (over 45% from each branch) in the single mode region of waveguide. Especially it transmits nearly 98% (49% from each branch) of the input light in the wavelength of 1550 nm. In other words, the proposed devise shows higher beam splitting efficiency and a wider range of flatness of transmission power spectrum in comparison with previous works.

Publisher:

Oficyna Wydawnicza Politechniki Wrocławskiej

Place of publication:

Date:

Resource Type:

Resource Identifier:

oai:dbc.wroc.pl:58565

Source:

<sygn. PWr A3481II> ; click here to follow the link ; click here to follow the link

Language:

Relation:

Optica Applicata ; Optica Applicata, Vol. 40, 2010 ; Optica Applicata, Vol. 40, 2010, nr 4 ; Politechnika Wrocławska. Wydział Podstawowych Problemów Techniki

Rights:

Wszystkie prawa zastrzeżone (Copyright)

Access Rights:

Dla wszystkich w zakresie dozwolonego użytku

Location:

Politechnika Wrocławska

Group publication title:

Optica Applicata

Subject and keywords:

optyka photonic crystal photonic band gap beam splitter T-junction finite difference time domain (FDTD)

Object collections:

Lower Silesian Digital Library > Participants of the Consortium > 01. Wrocław University of Technology > Journals WUoT > Journals published at Wrocław University of Technology > Optica Applicata

Lower Silesian Digital Library > Resources > 2. Czasopisma > Czasopisma współczesne

Lower Silesian Digital Library > Fields of science > 6. Nauki ścisłe i przyrodnicze

Last modified:

Jan 31, 2019

In our library since:

Jan 31, 2019

Number of object content hits:

53
